Computer Interface Unit

Owing to our commitment to quality and excellence, we have established a strong presence in the industry by manufacturing and supplying premium-quality Computer Interface Units. This interface unit serves as a shared connection through which two separate components of a computer system exchange information. The offered unit is assembled using quality-approved chips, wires, and other essential components along with advanced technology under the supervision of our skilled professionals. Furthermore, the Computer Interface Unit is widely appreciated in the market for its reliable performance, hassle-free operation, and long service life.

Key Features

  • Load v/s Displacement graph
  • LED indication for upper & lower limits
  • LED indication for upwards & downwards movement status
  • Allow dual channel Encoder inputs to measure elongation
  • Windows based graphical software
  • Auto calibration through software.
  • RS232 communication.
  • 10000 counts i.e. 0.1kg Least count on 1000 kg load cell
  • Suitable for tensile testing & compression testing machines
    • Enquiry Now

    Seamless Software & Sensor Integration

    This unit supports real-time data acquisition on Windows 7, 8, and 10 with convenient plug-and-play installation. It easily integrates with standard load cell, pressure, and displacement sensors, making it suitable for a variety of testing environments. The intuitive software enables simple data export, allowing users to efficiently analyze results and maintain organized records for material testing and industrial automation applications.

    Rugged Build for Industrial Performance

    Constructed using industrial-grade ABS and aluminum, the unit is designed to deliver reliable performance in demanding laboratory and industrial environments. With CE certification, built-in overload and short-circuit protection, and stable operation within a temperature range of 10°C to 40°C and humidity levels of 20–90% RH, it ensures safe and dependable operation. Its compact design, low power consumption of <50W, and adjustable test speed make it suitable for both benchtop setups and production-line applications.

    Precision Measurement & Reliable Control

    Experience accurate and dependable measurement with an accuracy of 0.5% of full scale and a resolution of 0.01 N. Factory calibration and supplied calibration certificates ensure compliance and reliable operation from the start. The microprocessor-based digital control system, combined with a digital LCD display, provides precise parameter adjustment and clear, user-friendly feedback for laboratory technicians and engineers.

    Product Details:

    • Automation Grade Semi-automatic
    • Port Size USB 2.0
    • Max Height 210 mm
    • Mounting Type Table Top
    • Specimen Size Customizable according to test requirements
    • Test Range 0-500 N
    • Display Type Digital LCD Display

    Computer Interface Unit Quantity

    • < 60 dB at full operation
    • Windows-based systems
    • Industrial grade ABS & Aluminum
    • 2 meters
    • Standard Serial Communication
    • Internal memory with data export capability
    • Windows 7/8/10
    • 285 x 200 x 75 mm
    • Load cell, Pressure sensor, Displacement sensor
    • Factory calibrated, Calibration certificate included
    • Manual & Automatic
    • < 50 W
    • Status and Power LEDs
    • Overload, Short-circuit
    • Single or Dual
    • CE certified
    • Grey & Black

    Computer Interface Unit Product Specifications

    • 20% to 90% RH, non-condensing
    • Microprocessor-based digital control
    • 0.01 N
    • Data Acquisition, Control & Monitoring
    • 10C to 40C
    • Single Specimen
    • 220 V AC, 50/60 Hz
    • Adjustable, up to 500 mm/min
    • Table Top
    • Customizable according to test requirements
    • Semi-automatic
    • USB 2.0
    • 210 mm
    • 0-500 N
    • Digital LCD Display
    • Computer Interface Unit
    • 220 V
    • 100 mm
    • USB, RS232
    • Approximately 7 kg
    • Material testing, Laboratory Analysis
    • 500 N
    • 120 mm
    • < 100 ms
    • Real-time data logging, User-friendly software, Plug and Play operations
    • 0.5% of full scale
    • 0-500 N
    • 50/60 Hz

    FAQs of Computer Interface Unit:


    Q: How do I connect sensors to the Computer Interface Unit for testing?

    A: The unit supports standard load cell, pressure, and displacement sensors. Simply plug your compatible sensor into the dedicated input channel. The USB 2.0 and RS232 ports facilitate quick connectivity, and the user-friendly software will recognize connected devices for immediate operation.


    Q: What operating systems and communication protocols are supported?

    A: This unit is designed for use with Windows 7, 8, and 10 systems. It uses standard serial communication, with USB and RS232 interfaces, enabling seamless data transfer and integration with most laboratory or industrial computers.


    Q: When do I need to recalibrate the device, and is a calibration certificate provided?

    A: Each unit is factory-calibrated and comes with an official calibration certificate. Recalibration is typically necessary after extended use, significant transportation, or as required by your labs quality standards. Please refer to your calibration schedule or consult the manufacturer for details.


    Q: Where can the unit be installed, and what are its mounting options?

    A: With its compact, table-top design and rugged construction, the Computer Interface Unit is ideal for laboratory benches, industrial facilities, or automation setups. It operates reliably within typical lab environments (temperature: 10C to 40C; humidity: 20% to 90% RH, non-condensing).


    Q: What is the process for exporting recorded data for analysis?

    A: After your tests, use the built-in software to export data from the units internal memory. Data can be saved in common formats for further analysis or reporting, ensuring seamless workflow integration for laboratory and quality assurance purposes.


    Q: How does the unit benefit users in material testing and laboratory analysis?

    A: The combination of high precision (0.5% FS), rapid response time (<100ms), and easy-to-use software streamlines testing procedures, ensures reliable results, and boosts efficiency for laboratory personnel and engineers. The versatility in sensor compatibility and adjustable testing parameters accommodate various material testing protocols.


    Q: Which protections does the device offer to ensure safe operation?

    A: The Computer Interface Unit is equipped with overload and short-circuit protection, indicator LEDs for status and power, and meets CE safety standards, ensuring a safe operating environment even during intensive laboratory or industrial material testing.
