Potentiometer-Type Angle Sensor

Innovative Systems offers reliable Potentiometer-Type Angle Sensor solutions for accurate angle measurement and position monitoring. Designed for industrial applications, it delivers fast response, stable analog output, and dependable performance in demanding operating conditions.

Key Features

  • Accurate angle measurement
  • 360° measuring range
  • 0.1° resolution
  • Fast response time
  • Analog voltage output
  • Low maintenance
  • Compact and rugged construction
  • IP67 protection
    • Enquiry Now

    Rugged Construction and Reliable Performance

    Built with an aluminum alloy housing and IP67 protection, the Potentiometer-Type Angle Sensor is designed for reliable operation in demanding industrial environments. Its operating temperature range of -40°C to +125°C supports stable performance under varying conditions.

    High Precision and Fast Response

    The Potentiometer-Type Angle Sensor provides 0.5% FS accuracy and 0.1° resolution for precise angle measurement. With a response time of less than 2 ms, it delivers fast feedback for automation, motion control, and position monitoring systems.

    Easy Installation and System Integration

    With 5V DC operation, 0.5V to 4.5V analog output, and a 3-wire cable connection, the sensor can be easily integrated with compatible controllers and monitoring systems. Its 0° to 360° measuring range supports a wide range of angle sensing applications.

    Product Details:

    • Resistance 10 kΩ
    • Output Analog Voltage
    • Theory Hall Sensor
    • Type Potentiometer-Type Angle Sensor
    • Accuracy 0.5% FS
    • Operating Voltage 5V DC
    • Output Voltage 0.5V to 4.5V

    Potentiometer-Type Angle Sensor Product Specifications

    • 0° to 360°
    • 0.1°
    • 0.5% FS
    • Analog Voltage
    • 0.5V to 4.5V
    • 5V DC
    • 10 kΩ
    • <2 ms
    • -40°C to +125°C
    • -20°C to +85°C
    • -55°C to +150°C
    • Hall Sensor
    • IP67
    • 3-Wire Cable
    • 45 mm × 20 mm × 12 mm
    • 35 g
    • Aluminum Alloy
    • Industrial Automation, Automotive & Position Monitoring
